The Acorn 180 Curved Stairlift

The Acorn 180 Stairlift is the most innovative stairlift in the world. A true technological breakthrough.

The Acorn 180 Stairlift can be installed on virtually any staircase, including curves, multiple landings, and more. Each Acorn 180 Stairlift is designed and installed to your precise requirements.

Want the stairlift to take you down the hall to your bedroom? The Acorn 180 can do that. Want it to take you into your living room? It can do that too

Bruno Elan Elite and Curved Stair Lift Dealer

bruno curved stairlifts





San Francisco Curved Stair Lifts
Serving Anaheim and Orange County Metropolitan Area with Curved Stair Lifts
12557 Harbor Blvd., Garden Grove CA  (800)824-3145


Aliso Viejo Curve Stair Lift Anaheim Curved StairLifts Brea Buena Park Costa Mesa Cypress Dana Point Fountain Valley Fullerton Garden Grove Huntington Beach Irvine La Habra La Palma Laguna Beach Laguna Hills Laguna Niguel Laguna Woods Lake Forest Los Alamitos Mission Viejo Newport Beach Orange Placentia Rancho Santa Margarita San Clemente San Juan Capistrano Santa Ana Seal Beach Stanton Tustin Villa Park Westminster Yorba Linda

Orange County Custom Curved Stair Lift Specialist Serving: Aliso Viejo Anaheim Brea Buena Park Costa Mesa Cypress Dana Point Fountain Valley Fullerton Garden Grove Huntington Beach Irvine La Habra La Palma Laguna Beach Laguna Hills Laguna Niguel Laguna Woods Lake Forest Los Alamitos Mission Viejo Newport Beach Orange Placentia Rancho Santa Margarita San Clemente San Juan Capistrano Santa Ana Seal Beach Stanton Tustin Villa Park Westminster Yorba Linda  (877)727-1954

CURVED STAIR LIFT @ THE WORLD'S LOWEST PRICE. CALL 877-727-1954.

Model: CRE 2110

Enjoy the stairlift built specifically for your home. Experience the smooth, quiet ride of Bruno's Elite Curve stair lift from start to finish. With Bruno's signature stairlift, the quality and comfort are second to none. Add power options to further customize your Elite curved chairlift to fit your lifestyle.

Receive a free consultation from a local Bruno dealer. Find out why Bruno receives great stairlift reviews and high customer ratings!

Bruno's signature, custom curved stairlift

Top-selling curved stairlift in North America

Multiple options for individual needs, tastes

Exceptionally smooth, quiet ride

Luxury quality, stylized chair

Custom-crafted to maximize stairway space

Offset swivel seat; flip-up arms; folding footrest/seat

Dependable power even in electric outage

Wireless call/send controls

Technical Specifications and Product Downloads

Blue Design Icon

Bruno Custom Curved StairChair Specs

Seat pad size:
17.5 in x 15 in deep (445 mm x 381 mm)

Footrest size:
10 in long x 9 in deep (254 x 229 mm)

Adjustable width armrests:
Up to 21.75 in (552mm) between arms

Power Icon

Bruno CRE2110 Power

Two 12-volt batteries

Charges at top or bottom of stairs or optional mid-park position

Shield Icon

Safety

Obstruction sensors

Seat belt

Offset swivel seat




Acorn 180 Curved StairLift Safety Features

The Acorn 180 Stairlift

The Acorn 180 Curved Stairlift is the most innovative stairlift in the world. A true technological breakthrough.

The Acorn 180 Stairlift can be installed on virtually any staircase, including curves, multiple landings, and more. Each Acorn 180 Stairlift is designed and installed to your precise requirements.

Want the stairlift to take you down the hall to your bedroom? The Acorn 180 can do that. Want it to take you into your living room? It can do that too.

A wealth of features for your benefit

  1. Padded seat and backrest for maximum comfort.
  2. Can be operated with the lightest of touches. Perfect for those with limited dexterity.
  3. A safety belt is installed on all of our stairlifts, so you feel secure at all times.
  4. Our slim fold away design has folding arms, seat and footrest, so other people can continue to use the stairs.
  5. A lockable swivel seat means you can get on and off your stairlift without twisting your body.
  6. Our modular rail system is secured directly to the stairs, not to the wall. So there's no structural damage to your home.
  7. Modular rail allows the rail portion of the lift to be quickly assembled from stock components, enabling faster delivery and an installation time to suit you.
  8. Safety sensors on the footrest and carriage stop the stairlift automatically if any obstruction is encountered.
  9. Hand-held remote controls allow users to call or send the lift up and down the staircase. Perfect for sharing with a loved one.
Acorn 180 Stairlift Dimensions

Dimensions

inch

A Overall height 38.25

B Height of Seat 17.25

C Overall depth (from wall) 25.25

D Overall depth (when folded) 13.25

E Width of footrest 14.75

F Overall width 24.5

G Depth of seat 16

This stairlift is independently tested to comply with:

  • BS EN 81-40:2008 - European safety standard - 'Specification for powered stairlifts'.
  • CE mark - Acorn Stairlift meets the requirements of the applicable European Directive(s).
  • ASME compliant for mechanical and electrical hazards - ASME A18.1 and A17.5.

Specifications

Motor output speed:  4.8 inches per second - No greater than 5.9 inches per second

Method of drive:  Rack & pinion

Power supply:  24V DC (battery)

Maximum capacity: 266lbs

Track:  Modular rail, extruded aluminium

Main supply:  50-60Hz, 100-240V AC

Optional equipmentAutomatic Powered Hinge

If there is a doorway near the foot of the stairs the optional automatic powered hinged rail is ideal.

The lower section of the rail folds up and out of the way automatically as the stairlift travels up and down the staircase, allowing greater access at the foot of the stairs. The powered hinge raises and lowers automatically as the stairlift travels up and down the staircase.

When the stairlift is not is use, the rail is neatly out of the way and causes no obstruction.





Measurement Form

The Helix Curved Stair Lift offers a narrow profile that mounts closer to the wall, with tighter bends. The ride is ultra smooth--and whisper quiet!

Every Helix CSL500 is engineered and built to order. Each custom stairlift is unique to the home and stairway it is installed to. This custom design allows the Helix stairlift to have a smaller footprint, quicker install, and outstanding performance.

The build and delivery methods also allow installers to work more quickly and efficiently when they arrive at your home. The lift can be installed with minimal disruptions to you.

Perfect for a stairway with a 90-degree turn, 180-degree turn, or even a spiral staircase. The Helix can even be built to accomodate multi-story applications.

An ergonomically-designed seat features swivel seat and "flip-up"" arms to make entry and exit easier.

Custom color and fabric options are available to help make the Helix Curved Stair Lift a tasteful addition to any home.

Authorized Harmar Helix Curved StairLift Dealer





Fastest Installation in the Anaheim on the Handicare Curved Stair Lifts

Curved stairlifts have tracks that are specifically designed to suit staircases that turn corners or are spiral. All Handicare curved tracks are made to order following a survey of each individual staircase. We offer you the following curved stairlifts:

Vermeer: the multi-storey stairlift

Vermeer

The perfect stairlift for reaching multiple storeys.

2000 curved stairlift

2000

The stairlift system with the tightest track bends available in the industry.

Van Gogh stairlift for your outside bend

Handicare Van Gogh

Our stairlift for your outside bend, giving you the most secured feeling.

Rembrandt stairlift for your inside bend

Rembrandt

The stairlift for the inside bend leaving plenty of space on your stairs.

2000 Stairlift for outdoor use

2000 Outdoor

Our Outdoor stairlift makes your garden accessible for anyone.



Hawle Documents

 Hawle Brochure

 Hawle Order Form - Fillable

 Overspeed Governor

 Stairlift Dimensions

 Stop Start Config

 ASME Installation and Service Manual

 ASME Owner's Manual
